Resolution (Live)

1920X1080

Sensor

1/2.7" (0.5x C-mount recommended); SONY IMX236

Frame Rate

HDMI (60fps); USB 2.0 (30fps)

Image Capture

High Speed SD Card (8GB)

Video Capture

HDMI:  1080p, 60fps to SD Card
USB 2.0:  1080p, 30fps to PC or Mac

Exposure Time

0.001 sec - 10.0 sec

White Balance

Auto

Settings

Gain, Gamma, Saturation, Contraction

Built-in Software

Cloud 1.0 (With live image measurement)

PC Imaging Software

CaptaVision Imaging Software (for PC only; Mac OS not supported)
Advanced Camera Controls: live/still image measurement and annotation, flat field correction; extended depth of focus (focus stacking); image stitching; fluorescence image settings; fluorescence multi-color channel merge; HDR (High Dynamic Range) function
Image Types: JPEG, BMP, TIFF and RAW

Output Modes

Mode 1:  USB 2.0 / Mode 2: HDMI

System Compatibility

Windows XP, Vista 7 and 8 (32 or 64-bit)

Mac OS X (for image transfer to Mac OS X only)

System Requirements

Intel processor (Core 2 Duo or higher); 2GB memory or more; USB 2.0 Hi-Speed port

Power Supply

DC12V/1A

Warranty

1 year

What's In the Box

Excelis HD Camera, HDMI Cable, USB 2.0 Cable, 12V Power Adapter, 8GB SD Card, USB Mouse, CaptaVision PC Imaging Software
