Unitron Z650HR Gemological Trinocular High Resolution Zoom Stereo Microscope on LED Incident & Transmitted Focusing Stand

$2,415.00 $2,174.00
(You save $241.00)

Unitron Z650HR Gemological Trinocular High Resolution Zoom Stereo Microscope on LED Incident & Transmitted Focusing Stand

$2,415.00 $2,174.00
(You save $241.00)
SKU:
U-13431-GEM
Weight:
22.00 LBS
Shipping:
Free Shipping
Quantity:
Share

Product Description

Z650HR Zoom Stereo Microscope Series

Utilizing a new optical design incorporating a total reflection prism system the Unitron Z650HR delivers higher resolution, higher contrast and brighter images for industrial, biomedical and educational applications than traditional Greenough stereos.  With a built-in camera port and a 0.55x c-mount adapter, cameras can be directly mounted to the Unitron Z650HR. Featuring an 8:1 zoom ratio (0.6x – 5.0x), a 115mm working distance and WF10x/23mm focusable eyepieces, the Z650HR is ideal for industrial inspection applications.  The Z650HR is a versatile, high performance, ergonomically designed zoom stereo microscope ruggedly built to withstand years of heavy usage.

Unitron Z650HR Gemological Trinocular High Resolution Zoom Stereo Microscope on LED Incident & Transmitted Focusing Stand

Trinocular viewing head, 0.6x to 5.0x zoom range, inclined at 30°,115 mm working distance,
interpupillary distance adj, 52-75mm, glass lens shield
Widefield 10x eyepieces with built-in diopter adjustment (paired) 23mm field of view, 0/100
light split, with 0.55x built-in c-mount lens
Variable LED incident (12v/2w) and transmitted (12v4w) focusing stand with stage clips,
universal power supply
Darkfield condenser w/adjustable iris diaphragm, wire stone holder (gem clamp)
Frosted, clear glass, 100mm black & white stage plates
Dust cover and instruction manual

Specifications

  • Variable LED Focusing Stand
  • 12v/2w variable LED incident light
  • 12v/4w variable LED transmitted light
  • 4 inches (100mm) of continuously smooth focus travel
  • Darkfield condenser with adjustable iris diaphragm
  • Wire stone holder/gem clip
  • Trinocular viewing body
  • WF10x focusable eyepieces, 23mm field of view
  • 6x – 50x magnification range with click stops at 1x, 2x, 3x, 4x and 5x
  • 115mm working distance

Standard Specifications

  • 0.6x – 5.0x zoom magnification range
  • Magnification range 6x-50x (with 10x eyepieces)
  • 8:1 zoom ratio
  • 30° viewing angle
  • 115mm working distance
  • Interpupillary Distance Adjustment 55mm – 75mm
  • WF10x/23mm focusing eyepieces with roll down eyeguards
  • Airtight and anti-mold design

Optional Accessories

LED ring lightsfiber optic illuminators and fluorescent ring illuminators, 0.3x, 0.63x and 2.0x auxiliary objectives, Digital cameras and c-mount adapters, 15x and 20x focusing eyepieces, Reticles and stage micrometers.
